Eaton Wiring Devices TRSGF15W-BOX/TRVG GFCI Duplex Receptacle, Nylon, White, 2-Pole, 15 A, 125 V, 60 Hz

Eaton Wiring Devices

$38.85~~$38.85~~

Color: White
Current Rating: 15 A
Dimensions: 4.2 in L x 1.68 in W x 1.27 in D
Frequency Rating: 60 Hz
Includes: Wallplate
Model #: TRGF15W-BX-L
UPC #: 032664743139
SKU: 9235821

Your shopping list will be used for pickup in-store

Product Details

GFCI receptacles are designed with the safety of the user in mind. In commercial and industrial areas like public bathrooms, breakrooms and food service areas, the NEC® requires GFCI receptacles. Arrow Hart self-test GFCI receptacles are UL listed and fully compliant with all of the latest UL943 Class A GFCI and UL498 requirements. The self-test GFCIs conduct an automatic test periodically to ensure GFCI protection. The device will trip and will not reset if GFCI protection is not available. Additionally, GFCIs incorporate a safety lock-out function to protect against miswired line load connections and GFCI circuitry damage.

Key Features

Performs periodic self-tests to ensure integrity of GFCI protection
Automatic grounding system eliminates need for bonding jumper in grounded metal enclosure, provides redundant measure of ground continuity where jumper is used
Ground termination with back wire clamp provides secure wiring and reduces installation time
Tamper-resistant shutters resist the insertion of foreign objects
Line side terminals are backed out and staked for fast installation
Horizontal test/reset button alignment provides larger unobstructed area
Test and reset buttons are color matched to provide great aesthetics
Tapered back wire openings handle multiple wire sizes and types for applications up to #10 AWG solid or stranded wire
When downstream receptacles are wired from load side, a 20 A feed-through rating offers full protection
Line-load miswiring protection

Item Specifications

Color	White
Current Rating	15 A
Dimensions	4.2 in L x 1.68 in W x 1.27 in D
Frequency Rating	60 Hz
Includes	Wallplate
Material	Nylon
Mounting Type	Wall

NEMA Configuration	5-15R
Number of Poles	2
Number Of Wires	3
Operating Temperature	-35 to 66 deg C
Voltage Rating	125 V
Wire Size	14 to 10 AWG
Wiring Type	Back Side

MORE DETAILS:

Application: For commercial, industrial and institutional uses areas like public bathrooms, breakrooms and food service areas
